Case Report
Vol. 3, Issue 1, 2023June 26, 2023 EDT

Purple Urine Bag Syndrome in a Woman with Squamous Cell Cervical Cancer

Rhea Eubanks, MD, Crystal Dupont, MD, Diane Fru, MD, Amanda Jackson, MD, Thomas Herzog, MD, Caroline Billingsley, MD,
purple urineurinary tract infectionnephrostomycatheter
Copyright Logoccby-4.0 • https://doi.org/10.54053/001c.82140
Photo by Testalize.me on Unsplash
NAPGO
1.
Eubanks R, Dupont C, Fru D, Jackson A, Herzog T, Billingsley C. Purple Urine Bag Syndrome in a Woman with Squamous Cell Cervical Cancer. NAPGO. 2023;3(1):1-6. doi:10.54053/​001c.82140
Save article as...▾
Download all (1)
  • Figure 1.
    Download

Sorry, something went wrong. Please try again.

If this problem reoccurs, please contact Scholastica Support

Error message:

undefined

View more stats

Abstract

Purple urine bag syndrome is a rare phenomenon whose striking presentation can lead to earlier recognition and treatment of a potentially serious medical condition. This is a unique condition of long11 term indwelling catheter associated urinary tract infection with distinct, purple-colored urine caused by bacterial metabolites. This infrequent occurrence was seen in a patient with stage IIIb squamous cervical cancer who presented to the emergency department with symptoms of a urinary tract infection in setting of indwelling bilateral percutaneous nephrostomy tubes. The patient’s physical exam was notable for left costovertebral tenderness, purple urine in bilateral nephrostomy bags and urine culture significant for proteus mirabalis. The patient was treated with intravenous antibiotics and fluid resuscitation. She unfortunately left against medical advice shortly after being admitted. She re presented to an outside hospital with fevers and non-draining nephrostomy tubes notable to have purulent discharge at the nephrostomy sites. The scant urine through the nephrostomy tubes was also noted to have a purple hue. She was found to have another urinary tract infection with Enterobacter cloacae and subsequently treated with intravenous antibiotics. During this admission, she underwent bilateral nephrostograms notable for significant clogging of tubes and bilateral ureteral patency. After the study, she underwent removal of the long-term indwelling catheters and was able to continue voiding spontaneously. She was discharged in good condition on a ten-day course of oral antibiotics.

The occurrence of purple urine is highly associated with urinary tract infections. This process is thought to be caused by a metabolism of dietary tryptophan by intestinal bacteria to indole that is then absorbed into the circulation and then converted to indoxyl sulfate by hepatic enzymes. This substrate returns to circulation and is excreted in the urine where in the presence of bacteria with sulfatase and phosphatase activity converts indoxyl sulfate to indigo and indirubin resulting in the characteristic purple hue of the urine. Catheter associated urinary tract infections require antibiotic treatment and timely removal of catheter when appropriate to prevent complications including pyelonephritis and sepsis.

Introduction

Purple urine bag syndrome is a rare phenomenon whose striking presentation can lead to earlier recognition and treatment of a serious medical condition. This is a unique condition of catheter associated urinary tract infections caused by bacterial metabolites. The most important risk factor of developing catheter associated urinary tract infection is length of catherization as risk is 3-10% per day.1 Other risk factors include female sex, diabetes mellitus and bacterial colonization within the urine bag.1 We will demonstrate a case of this rare phenomenon in a patient with squamous cervical cancer who presented to the emergency department with symptoms of a urinary tract infection.

Case Description

The patient is a 34-year-old G3P3003 with a history of stage IIIb squamous cell cervical cancer diagnosed in December of 2020. Her treatment included 45Gy of external beam radiation with a boost of brachytherapy radiation and only 2 cycles of cisplatin chemotherapy complicated ultimately by loss to follow up. Her cancer course was complicated by bilateral hydronephrosis due to obstruction and subsequent bilateral percutaneous nephrostomy tube (PCN) placement. She presented to the emergency department with decreased urinary output from the bilateral PCNs and left flank pain. She reported decreased urinary output from the PCNs over the preceding month. She expressed she was supposed to have the nephrostomy tubes removed four to five weeks after the second exchange; however, they have remained in place for seven months. The patient also accounted she last changed the nephrostomy bags four weeks prior to her presentation to the emergency department. She mentioned that she was voiding via urethra but also noticed increased urinary frequency and urgency as well as accompanied persistent back pain. She denied dysuria or hematuria. Of note, the patient reported having change in urine color in the nephrostomy bags. She remarked that two weeks prior to her presentation to the emergency department, the color started to change from a yellow-green hue before transitioning to a purple color. She had experienced intermittent chills, but she denied having a fever. The patient was noted to be mildly hypertensive, non-tachycardic and afebrile while in the emergency department. Her physical exam was significant for left costovertebral tenderness and bilateral PCN bags with purple urine. There was no evidence of leukocytosis or electrolyte abnormalities on laboratory values. A urine analysis was collected and significant for pyuria and proteinuria. A urine culture obtained was noteworthy for >100,000cfu/ml proteus mirabalis. Blood cultures were drawn and found to have no growth to date for more than five days. The patient received intravenous antibiotics and intravenous fluids to treat urine tract infection in the emergency room. She was admitted to the hospital but unfortunately left against medical advice shortly after admission. She re-presented to an outside hospital with fevers and non-draining nephrostomy tubes associated with purulent discharge at the nephrostomy sites. The scant urine through the nephrostomy tubes was also noted to have a purple hue. She was found to have another urinary tract infection with Enterobacter cloacae treated initially with intravenous antibiotics. During this admission, she underwent bilateral nephrostograms notable for significant clogging of tubes and bilateral ureteral patency. After the study, she subsequently had her PCNs removed. She was discharged in good and improved condition on a ten-day course of outpatient oral antibiotics.

Figure 1
Figure 1.

Discussion

Evaluation of patient urine is not a new tool for assessment of disease. There is data to suggest that ancient civilizations performed urinalysis and uroscopy. “Honey urine” has been described in ancient Sanskrit literature as sweet to the taste with the ability to attract black ants, later determined to be secondary to glucosuria as seen in diabetes.2 In the 14th century, with the aid of matula and urine charts, it was believed that one could diagnose several diseases based on urine color alone.2 From urine charts, taste testing, and now modern-day urinalysis, assessment of urine has become one of the mainstays of initial patient evaluation.

Purple urine bag syndrome was first described in 1978 when it was noted that urine in collecting bags turned purple. After spectral analysis of the urine, it was observed that indigo was present. At that time, it was hypothesized that increased bacterial metabolism in the intestinal lumen resulted in indoxyl sulfate. This would be absorbed and excreted which oxidized to indigo upon contact with the air in the collection bag, resulting in purple colored urine.3 It is also postulated that King George III may have also had purple urine after constipation in the setting of presumed acute intermittent porphyria. This constipation would lead to increased dietary tryptophan metabolism, subsequent indole production, metabolism to indoxyl sulfate, and later indigo blue formation.4

In recent years, purple urine in bag syndrome (PUBS) has been defined as a condition characterized by urine with purple discoloration in patients with urinary tract infection. As detailed in Table 1, other risk factors include indwelling catheterization, female sex, elderly age, asymptomatic bacteriuria, chronic kidney disease, urine alkalinization, and constipation. Conditions that lead to dietary tryptophan having increased time spent in the digestive tract have been considered predisposing conditions for PUBS (constipation, malabsorption, etc).5–8

Table 1.Associated Risk Factor
Female
Indwelling Catheter
Malabsorption, Constipation
Chronic Kidney Disease
End Stage Renal Disease
Diabetes Mellitus
Elderly
Dementia
Long Stay in Acute Care Facility

The pathophysiology behind this condition has further been explained by digestion of dietary tryptophan by intestinal bacteria to indole that is then absorbed into the circulation. Later, in the liver, it is acted on by cytochrome P450 2E1 (CYP2E1) and sulfotransferase 1A1 (SULT1A1) isoform to become indoxyl sulfate. This substrate returns to circulation and is excreted in the urine where in the presence of bacteria with sulfatase and phosphatase activity converts indoxyl sulfate to indigo and indirubin resulting in the characteristic hue of the urine. Providencia stuartii, Pseudomonas aeruginosa, Escherichia coli (E.coli), Proteus mirabilis, Morganella morganii (M. morganii), Klebsiella pneumoniae, Providencia rettgeri, Citrobacter species, Enterococci, and Group B Streptococci are the most common bacteria with the sulfatase and phosphatase activity required.5–10

PUBS is generally considered a benign process; however, treatment should not be delayed as overall mortality related to PUBS has been reported as 6.8%.11 If the infection is not treated it can progress to sepsis. Prior literature reviews have identified rare cases where PUBS progressed to Fournier’s gangrene or multi-drug resistant vulvar abscesses.5,10–14 Indoxyl sulfate has been noted to accumulate in the serum in patients with chronic kidney disease. In the serum it is primarily protein bound and is not readily cleared during dialysis since only unbound indoxyl sulfate can diffuse through the membrane. Accumulation of indoxyl sulfate has been implicated in contributing to further renal failure, vascular disease, cognitive impairment.1 However, the majority of these effects have primarily been assessed in vitro or in animal models. Human toxicity will need further research. When PUBS is suspected further medical evaluation and treatment should be sought as soon as possible.

Once identified, treatment of the urinary tract infection should be aimed at causative bacteria. Additionally, any predisposing condition (constipation) or risk factors should be addressed. This often entails intravenous antibiotics until the urine has returned to normal coloration followed by transition to oral antibiotics, exchange of the urinary catheter, bowel regimen, or evaluation of renal status in CKD patients.5,6,10–13 If a patient presents sepsis or shock, treatment for underlying infection and resuscitation should be initiated. Based on literature review, patients tend to have resolution of purple discoloration with completion of antibiotic treatment and exchange of urine bag.15,16 As with the patient, she initially had initiation of empiric antibiotic treatment; however, left against medical advice prior to completion of medical management. She had a delayed course in care but ultimately completed treatment with directed antibiotics for her urinary tract infection and with removal of percutaneous nephrostomy tubes. Reports of progression of disease in patients who initially presented with purple urine and asymptomatic bacteriuria support the need for treatment and further evaluation in a patient with sudden development of purple urine who is otherwise asymptomatic.1

Conclusion

Health care providers need to be aware of purple urine bag syndrome as it is a condition that can often be diagnosed with visual evaluation of a patient’s urine. Although in many cases benign, without treatment, urinary tract infections can lead to pyelonephritis, sepsis, bacteremia and even death.17 The best prevention of catheter associated urinary infections is stewardship of indwelling catheters including sterile placement and prompt removal as soon as catheter is no longer needed.


Conflict of Interest

There is no conflict of interest to report.

Disclosures

There are no disclosures. Patient consent was obtained.

Author Contribution

Rhea Eubanks, MD: Conceptualization, Methodology, Writing- Original Draft, Writing- Review and Editing Crystal Dupont, MD: Methodology, Writing-Original Draft, Diane Fru, MD: Methodology, Writing-Original Draft Amanda Jackson: Writing- Review and Editing Thomas Herzog, MD: Writing-Review and Editing Caroline Billingsley, MD: Writing-Review and Editing, Supervision

Submitted: March 29, 2023 EDT

Accepted: May 30, 2023 EDT

References

1.
Leong S, Sirich T. Indoxyl Sulfate—Review of Toxicity and Therapeutic Strategies. Toxins. 2016;8(12):358. doi:10.3390/​toxins8120358. PMID:27916890
Google ScholarPubMed CentralPubMed
2.
Antic T, DeMay RM. The fascinating history of urine examination. J Am Soc Cytopathol. 2014;3(2):103-107. doi:10.1016/​j.jasc.2013.12.005
Google Scholar
3.
Barlow GB, Dickson JAS. Purple urine bags. The Lancet. 1978;28:220-221.
Google Scholar
4.
Arnold WN. King George III’s urine and indigo blue. Lancet. 1996;347(9018):1811-1813. doi:10.1016/​s0140-6736(96)91622-0
Google Scholar
5.
Yang HW, Su YJ. Trends in the epidemiology of purple urine bag syndrome: A systematic review. Biomed Rep. 2018;8(3):249-256. doi:10.3892/​br.2018.1046. PMID:29564123
Google ScholarPubMed CentralPubMed
6.
Sabanis N, Paschou E, Papanikolaou P, Zagkotsis G. Purple Urine Bag Syndrome: More Than Eyes Can See. Curr Urol. 2019;13(3):125-132. doi:10.1159/​000499281. PMID:31933590
Google ScholarPubMed CentralPubMed
7.
Kang KH, Jeong KH, Baik SK, et al. Purple urine bag syndrome: case report and literature review. Clin Nephrol. 2011;75(6):557-559. doi:10.5414/​cn106615
Google Scholar
8.
Evans R, Allan M, Walsh S. Purple urinary bag syndrome. BMJ Case Rep. 2014;2014:bcr2014207483. doi:10.1136/​bcr-2014-207483. PMID:25385567
Google ScholarPubMed CentralPubMed
9.
Dealler SF, Hawkey PM, Millar MR. Enzymatic degradation of urinary indoxyl sulfate by Providencia stuartii and Klebsiella pneumoniae causes the purple urine bag syndrome. J Clin Microbiol. 1988;26(10):2152-2156. doi:10.1128/​jcm.26.10.2152-2156.1988. PMID:2846640
Google ScholarPubMed CentralPubMed
10.
Khan F, Chaudhry MA, Qureshi N, Cowley B. Purple urine bag syndrome: An Alarming Hue? A Brief Review of the Literature. Int J Nephrol. Published online 2011. doi:10.4061/​2011/​419213. PMID:21977321
Google ScholarPubMed CentralPubMed
11.
Worku DA. Purple urine bag syndrome: An unusual but important manifestation of urinary tract infection. Case report and literature review. SAGE Open Med Case Rep. 2019;7:2050313X18823105. doi:10.1177/​2050313x18823105. PMID:30719299
Google ScholarPubMed CentralPubMed
12.
Vallejo-Manzur F, Mireles-Cabodevila E, Varon J. Purple urine bag syndrome. Am J Emerg Med. 2005;23(4):521-524. doi:10.1016/​j.ajem.2004.10.006
Google Scholar
13.
Kojima TGH. Purple urine bag syndrome. JAMA. 2012;307(18):1912-1913. doi:10.1001/​jama.2012.3540
Google Scholar
14.
Tasi YM, Huang MS, Yang CJ, Yeh SM, Liu CC. Purple urine bag syndrome, not always a benign process. Am J Emerg Med. 2009;27(7):895-897. doi:10.1016/​j.ajem.2009.01.030
Google Scholar
15.
Yaqub S, Mohkum S, Mukhtar KN. Purple urine bag syndrome: A case report and review of literature. Indian J Nephrol. 2013;23(2):140-142. doi:10.4103/​0971-4065.109442. PMID:23716923
Google ScholarPubMed CentralPubMed
16.
Al Montasir A, Al Mustaque A. Purple urine bag syndrome. J Family Med Prim Care. 2013;2(1):104-105. doi:10.4103/​2249-4863.109970. PMID:24479059
Google ScholarPubMed CentralPubMed
17.
Fekete T. Catheter-associated urinary tract infections in adults. UpToDate.
